I wanted to improve the space in the entrance, and we really needed a storage (bike helmets, caps, motorbike equipment...a lot of stuff). Making a piece of furniture is something I had in mind for a long time....but I was not sure If I was capable to do so.Well I tried and.....I'm really pleased with my work!! There is definitely things to improve, but it's not bad as a first try! What do you think?
So, if you feel inspired, here is the tutorial.
It's a real DIY, it's mean I used basic supplies (nails, screws and glue) and simple powers tools (drill and sanding machine). It's definitely not a carpenter work, but this means you can do it by yourself!
Supplies:plywood 16mm, nails 1.5', small metal brackets , screws, wooden glue, stain, paint
hammer, drill, sanding machine, ruler, pencil, brushes,
You need to cut the plywood panels, dimensions are:
2 pieces 38 x 12 cm
1 piece 92 x 12 cm
2 pieces 40 x 122 cm (top & bottom)
1 piece 40 x 118.8 cm (middle shelf)
2 pieces 40 x 68.8 cm (sides)
1 piece 40 x 41 cm (vertical division)
1 piece 40 x 26 cm (vertical division)
2 pieces 26 x 58.5 cm (back)
2 pieces 41 x 58.5 cm (back)
2 small drawers:
4 pieces 58 x 25.5 cm (front & back)
4 pieces 35 x 25.5 cm (sides)
2 pieces 54.8 x 35 cm (bottoms)
2 big drawers:
4 pieces 58 x 40 cm (front & back)
4 pieces 35 x 40 cm (sides)
2 pieces 54.8 x 35 cm (bottoms)
Sorry it's in centimeters...does someone know how to make the conversion to the US metric system?
I ask Google but the measurements are accurate for this tutorial and I don't want to screw up!
Step 1: make the feet
Glue two pieces of 38 x 12 cm together. Fix in between the 92 x 12 cm piece. Screw some brackets to be sure it's perpendicular.
Step 2: mark the measurements
Draw on the side panels the position of the middle shelf. Draw on the bottom, top and middle shelf, the position of the two vertical divisions. This will help a lot when you will have to nail the panels together. It's easier to do it before assembling!
Step 3: make the structure
Nail and glue the bottom with the side panels. Do the same with the vertical division in the middle (where you drew the position) and the two back pieces 41 x 58.5 cm.
Warning: Those two back pieces are missing in my tutorial because the wood store forgot them (to delivery or to cut ... I don't want to know why they screwed up)
Next you will have to nail and glue the middle shelf with the side and the vertical division. Before doing it, you need to put nails in both directions in the center of the middle shelf (where you drew). Some nails will help to fix the lower panel and some other to fix the top panel.
Then you nail and glue the two back panels and the vertical division. Again the two lower back panels are missing in the picture. Finish by nailing and gluing the top.
Step 4: Fix the feet
Nail and glue the feet with the structure. Take the measurements to have it centered.
Step 5: Make the drawers
Take the bottom drawer piece 54.8 x 35 cm, glue and nail the sides on it.
You also need to nail and glue the sides together.
Step 6: Stain & paint
Stain the structure in dark, and paint the drawers front in white.
Step 7: Make the handles
I choose to upcycle an old leather belt to make the handles, but you can use other hardware if you like to. Cut the belt into 4 and drill 2 holes in each leather piece. Drill two holes in each drawer front, and fix the handle with bolts and nuts.
Put the drawers back in place and TADAAAAAM!!!
Conclusions: I'm really happy with my new piece of furniture. I didn't use any sliders for the drawers, so they are a little heavy. It's ok because the unit in the entrance and I don't use it that often. But it will definitely not work for a daily use.
Next project for the entrance: put something a little more fancy on the walls...any suggestion?
